SPECIFICATIONS | |
Frequency Response (Figure 1) | |
50 to 17,000 Hz | |
Polar Pattern (Figure 2) | |
Output Impedance (at 1,000 Hz) Rated at 150 Ω (180 Ω actual) | |
Open Circuit Sensitivity | |
At 1 kHz, ref. 1 V per Pascal* | |
Cardioid: | –33.5 dBV (21.1 mV) |
Supercardioid: | –32.5 dBV (23.7 mV) |
Omnidirectional: | –28.0 dBV (39.8 mV) |
* 1 Pascal=94 dB SPL | |
Maximum SPL (1kHz at 1% THD, 1 kΩ load) Cardioid: 123.0 dB | |
Supercardioid: 122.0 dB | |
Omnidirectional: 117.5 dB | |
Equivalent Output Noise (A-weighted) Cardioid: 29.0 dB SPL | |
Supercardioid: 28.0 dB SPL | |
Omnidirectional: 70.5 dB SPL | |
Signal to Noise Ratio (referenced at 94 dB SPL) Cardioid: 65.0 dB | |
Supercardioid: | 66.0 dB |
Omnidirectional: | 70.5 dB |
Dynamic Range with 1 kΩ load | |
94.0 dB | |
Common Mode Rejection | |
45.0 dB minimum | |
Mute Switch Attenuation | |
50.0 dB minimum | |
Preamplifier Output Clipping Level (1% THD) | |
–6.0 dBV (0.5 V) | |
Polarity | |
Positive sound pressure on diaphram produces positive voltage | |
on pin 2 relative to pin 3 of XLR output connector. |
